• Advanced Purification
• Water storage capacity of 7 litres Mineraliser : adds required minerals and maintain the right pH of water
• Purification Process, Tank Full and Fault Indication
• Sleek design
• Storage Capacity
• In Tank UV Sterilization
• Removes turbidity, chlorine, and a wide range of organics such as pesticides, bacteria, virus,THMs etc.
• Wall Mounted Installation

The water we get in restaurants and at our home is mostly contaminated with bacteria, heavy metal, virus, pesticide, etc. Drinking contaminated water can cause waterborne diseases. This list of impurities also include viruses and heavy metals that ordinary filters cannot wipe out. To protect yourself from any health ailments from water contaminants, it is vital to install a powerful RO technology water purifier. An advanced RO filter can easily eliminate the impurities to make water pure and safe for drinking. You can buy this water purifier online at a reasonable price.

Designed to fit on your kitchen wall comfortably, Livpure Bolt Plus RO offers a counter-top and wall hanging option for flexible use. The RO is built with an adequate 8-litre capacity to store water and advanced RO + UV + Mineraliser technology. A convenient shutter tray is available to place bottles and glass while filling water.

Additionally, the water purifier is available in three replaceable colors to match your modular kitchen. The RO also facilitates a fast flow rate of 15 litre per hour. The service contact number is mentioned on the display panel for our convenience.

Mentioned below are 6 stages of the water purification process:

Super sediment Filter: It removes coarse and fine suspended dirt impurities from water.

PA Filter : It enhances the performance of entire purification system and thus ensures the good water quality consistently.

Carbon Block Filter :It adsorbs residual chlorine and hazardous impurities such as harmful pesticides from water. It also adsorbs bad taste, color and odor causing organic compounds from water.

Reverse Osmosis (RO) Membrane : It removes bacteria, virus, protozoa & parasites and reduces dissolved salts, hardness, pesticides and heavy metals from water.

Mineral Cartridge: It improves the essential minerals which enhance the taste & quality of water. It adds the required minerals to purified water and balances the pH of purified water to alkaline range.

In tank UV Sterilization: It keeps stored water absolutely safe for drinking for longer duration by UV sterilization at every hour.

Purification Technology	RO + UV + Mineraliser
Purification Capacity	Upto 12 litres/hour
Max. Duty Cycle	Upto 75 litres/day
Storage Tank Capacity	7 Litres
RO Membrane	75 GPD (Gallons Per Day)
Purification Cartridges	Super sediment Filter, PA Filter, Carbon Block Filter, RO Membrane, Mineral Cartridge, In tank UV sterilization
Ultra Violet LED	0.7 Watt
Min. Inlet Pressure	0.3 Kg/Sq.cm*
Max. Inlet Pressure	3 Kg/Sq.cm**
Input Voltage	140-300 V AC / 50 Hz
Operating Voltage	24 V DC

NOTE:-

• 1. Input Raw Water temperature should be between 10°C to 45°C. .
• 2.Total Dissolved Solids in input raw water should not exceed 2000 ppm.
• 3. Raw Water should be free from oil & grease.
• 4. Permissible Iron content in input raw water is 0.3 mg/L (max).
• 5. Total Hardness in input raw water should not exceed 600 mg/L (max).
• * If input water pressure is below 0.3 kg/Sq.cm, use of booster pump attachment is recommended to increase input water pressure and proper functioning of the unit. Flow rate depends on the input water pressure and condition of the filters
• ** If input water pressure is above 3.0 kg/Sq.cm, use of pressure reducing valve is recommended for leak proof and smooth functioning of the unit.
• # Manufacturer reserves the right to change/replace/upgrade any part of component in pursuit of providing continuous improvement in the quality of the products to its esteemed customers.

Flow Diagram:-

• 7 Stage Purification Process


• Water Storage Capacity Of 8 Litres


• Counter Top And Wall Hanging Option


• Convenient Shutter Tray

The water we get in restaurants and at our home is mostly contaminated with bacteria, heavy metal, virus, pesticide, etc. Drinking contaminated water can cause waterborne diseases. This list of impurities also include viruses and heavy metals that ordinary filters cannot wipe out. To protect yourself from any health ailments from water contaminants, it is vital to install a powerful RO technology water purifier. An advanced RO filter can easily eliminate the impurities to make water pure and safe for drinking. You can buy this water purifier online at a reasonable price.

Designed to fit on your kitchen wall comfortably, Livpure Envy Plus RO offers a counter-top and wall hanging option for flexible use. The RO is built with an adequate 8-litre capacity to store water and advanced RO + UV + UF + Taste Enhancer technology. A convenient shutter tray is available to place bottles and glass while filling water.

Additionally, the water purifier is available in three replaceable colors to match your modular kitchen. The RO also facilitates a fast flow rate of 15 litre per hour. The service contact number is mentioned on the display panel for our convenience.

Mentioned below are 7 stages of the water purification process:

Pre-Filter: The water is first run through the pre-filter for removal of physical impurities.

Sediment Filter: The partially filtered water is then run through the sediment filter to remove fine and coarse particles.

Pre-Activated Carbon Granular Filter: Pesticides, herbicides and other hazardous impurities like residual chlorine are absorbed by carbon filter. This filter also eliminates odor, bad taste, and organic compounds from water.

Reverse Osmosis (RO) Membrane: RO membrane helps in getting rid of hazardous chemicals such as THMs, heavy metals, pesticides, herbicides and other salts of the water. RO membrane is also useful in getting rid of virus, protozoa, bacteria, and eliminates any microbiological threats.

Ultra Violet (UV) Disinfection Column: In this stage, water is treated using UV radiation to eliminate waterborne disease-causing microbes such as bacteria, protozoa, and virus, to make it pure.

Ultra Filtration Cartridge: Impurities like cysts, bacteria, giardia, etc. are eliminated from water in this stage. It also removes suspended impurities from the water to make it clearer.

Silver Impregnated Post Carbon Cartridge: In this final stage, the Silver Cartridge effectively removes volatile organic impurities, giving odorless and pure water.

This latest water purifier is available in different color panels and also equipped with a convenient shutter tray.

Storage Tank Capacity	8 Litres
Purification Cartridges	Pre Filter Sediment Filter Pre Carbon Filter cum Adsorber RO Membrane UV Disinfection Column UF Cartridge Silver Impregnated Post Carbon Cartridge
Material Of Construction	Food Grade Material
Product Dimension (W*D*H) (Mm)	405*293*519
Installation	Table Top and Wall Mounting
Purification Technology	RO+UV+UF+Taste Enhancer
Stages Of Purification	7 Stages
Total Dissolved Solids (TDS) Levels	Upto 2000 ppm
Purification Capacity	Upto 12 Litres/hour*
Type Of Purifier	Electric
Max Duty Cycle	Upto 75 Litres/day
Filter Replacement Cycle	Upto 6000 Litres *Filter life may affect by input water Quality
RO Membrane	75-80 Gallons Per Day
Membrane Type	Thin Film Composite
UV Disinfection Column	24 Litres/hour (Design Registration No.- 264546)
UF Cartridge	0.1 µm
Maximum Inlet Pressure	3 Kg/Sq.cm**
Minimum Inlet Pressure	0.3 Kg/Sq.cm*
Input Voltage	140-300 V AC/50 Hz
Operating Voltage	24 V DC
Indicator	N/A
Alarms	UV Failure Alarm
Auto Shut Off	Yes
Replacement Cycle	6000 Litres
Sales Package	Product, Pre Filter, Installation kit, User Manual cum warranty card
Service Type	Onsite service, during warranty period sediment filter and activated carbon filter will be replaced and two preventive maintenance will be provided free
